ADJ VIZI HYBRID 16R
ADJ VIZI HYBRID 16R
ADJ LIGHTING CYPRUS
Hybrid Moving Head fixture
OVERVIEW
A true Spot/Beam/Wash hybrid Moving Head fixture, the ADJ Vizi Hybrid 16RX features Prism Morphing, motorized zoom, motorized focus and Power Twist In. Other professional features include: Frost filter to turn the hard edge beam to a wash, 6 & 8-facet rotating prisms, stepper motors for quick, precise movement.
The Vizi Hybrid 16RX Moving Head fixture is powered by the revolutionary Philips® Platinum 16R discharge lamp technology (8000˚K, 1,500 hr). The powerful Platinum 16R has an output comparable to a 575W fixture, with double the output of a 250W fixture. It also offers a flat, even spot field and even more saturation of colors. The Vizi Hybrid 16RX is much faster than previous ADJ moving heads because it is much lighter in weight and more compact than other moving heads in its class.
+ Features
- Prism Morphing
- Gobo scroll mode
- LED DMX 4-Button menu system
- Auto X-Y repositioning
- Gobo Shake effect for both wheels
- Independent gobo and color wheels
- Pan/Tilt Invert
- 16-Bit Pan/Tilt positioning
- Pan/Tilt speed adjustment
- Prism rotation
- Motorized Focus
- Motorized Zoom
- Shutter: Pulse effect; random strobe slow to fast
- Electronic Dimming: 0% - 100%
- Strobe effect
- Frost Filter for wash effect
- Omega Quicklock Brackets included
+ Specifications
- 19 DMX channels
- Pan: 540/360-degree
- Tilt: 270-degree
- Stepper motors with micro stepping
- 3-32 degree beam angle angle
- 14 colors + white
- 2 Separate Gobo Wheels: Wheel 1 - 16 static, fixed gobos + spot. Wheel 2 – 12 Colored, interchangable, rotating Glass Gobos + spot.
- 6 & 8-facet Prism with macros
- Gobo & Prism Morphing
- 3/5-pin XLR In/Out
- LUX: 770000 @ 5M, 220000 @ 10M
- Power Twist In
- Power Consumption: 537W
- Multi-voltage Operation: 100-240V, 50Hz/60Hz
- Lamp: Philips® Platinum 16R MSD discharge, 8,000˚K – 1,500 hr. long life
- Dimensions (LxWxH): 325 x 370 x 571mm
- Weight: 23 kg
